While troubleshooting a MultiLink Trunking (MLT) and split MultiLink Trunking (SMLT) network a need arises to determine which link packets are traversing. Which feature should be used to facilitate the troubleshooting?

A. Ping Trace

B. Ping Snoop

C. Snoop Trace

D. Trace Route

To provide load distribution across two or more equal cost paths in a Layer 3 routing environment, the ECMP feature can be used to maximize load sharing. Which two statements correctly describe the ECMP features? (Choose two)

A. All ECMP next hop addresses are in the routing table

B. ECMP keeps traffic between two IP addresses on one single path.

C. All ECMP paths are active and forwarding traffic.

D. ECMP routes apply to OSPF, RIP and BGP only.

Refer to the exhibit.

A campus network has been established with four Ethernet Routing Switch (ERS) 8600 switches in a switch cluster, two pairs with an Inter Switch Trunks (IST) running Split Multi Link Trunk (SMLT) and Routed Split Multi-Link Trunking (RSMLT). The traffic filters are required to block specific source IP addresses to be forwarded through the core.

With reference to the exhibit, how should these filters be set up?

A. Configure the filters on the 1ST first before any other ports.

B. Apply the filters to all ports that receive traffic from outside the immediate switch cluster.

C. Configure the filters on the ports first and then the IST.

D. Configure and apply all the filters on the two core IST links only

Consider the fallowing port conditions on an Ethernet Routing Switch (ERS) 8648GTRS 10/100/1000 Ethernet I/O module left LED -green Right LED - flashing

green.

What is the status of the port?

A. The link speed is 100 Mbps. and the port is disabled.

B. The link speed is 1000 Mbps, and the port is disabled

C. The link speed is 100 Mbps. and the port is passing traffic.

D. The link speed is 1000 Mbps. and the port is passing traffic.

A network has some Ethernet Routing Switch (ERS) 5500 switches licensed at the advanced level for Release 6 2 A technician implementing Protocol independent Multicast - Sparse Mode (PIM-SM) Which licensing requirement applies?

A. the PIM-SM is already covered by the existing advanced feature license

B. the PIM-SM con only be licensed on ERS 5510 models

C. the PIM-SM is included m the base license with release 6.2

D. A Premier license is needed
