ACD200 Online Practice Questions and Answers

Correct Answer: C

The question is about initiating a process via an Appian web API. The HTTP request method that the API should use is POST, as it is the method that allows sending data to the server and creating or updating a resource. In this case, the data would be the process parameters and the resource would be the process instance. The other options are not suitable for this purpose, as they either do not allow sending data or do not create or update a resource. References: HTTP Request Methods Start Process Web API

Correct Answer: C

The requirement is to create a service account for a consumer to access the Appian Web API. A basic user is the user type that should be created for this purpose, as it has the minimum permissions needed to invoke web APIs and does not consume a license. A basic user can also be assigned to specific groups or roles to control the access to web APIs. The other options are not suitable for this purpose, as they either have more permissions than needed or consume a license. References: User Types Web API Security

Correct Answer: B

The minimum privilege the end user should have to execute a web API is Viewer. A web API is an Appian object that exposes data and services to outside systems through an HTTP endpoint. A web API can be configured with different security role maps that control which users can see or modify it and its properties. A user must have at least Viewer permissions to a web API in order to execute it. Viewer permissions allow the user to view and run the web API, but not to edit or delete it. References: Web APIs, Web API Security

Correct Answer: A

The type of plug-in that should be created to perform a job in the background and not be available under an expression rule, connected system, or the process model is a servlet plug-in. A servlet plug-in is a plug-in that allows you to create custom servlets that can be accessed through a URL. Servlets are Java classes that run on a web server and handle requests and responses. Servlet plug-ins can be used to perform background tasks, such as sending notifications, logging events, or integrating with external systems, without exposing them to the end users or developers. References: Servlet Plug-ins, Appian Suite Plug-ins

Correct Answer: ABE

Correct Answer: AC

Object security settings can be changed in bulk in the application security summary and the compare and deploy tool. The application security summary provides a centralized view of the security role maps for all objects in an application. You can filter, sort, and edit the role maps from this view. The compare and deploy tool allows you to compare objects between two environments and deploy changes from one environment to another. You can also edit the role maps of the objects before deploying them. References: Application Security Summary, Compare and Deploy Tool

Correct Answer: BCD

Activity chaining is a feature that allows users to complete multiple tasks in a row without returning to their task list. However, activity chaining can also have some drawbacks, such as increased memory consumption, longer transaction times,

and reduced user feedback. Therefore, some actions can be taken to make the process model more efficient, such as:

Shorten long process chains by combining transactions into the smallest number of nodes. This can reduce the memory footprint and the database load of the process model.

Avoid chaining system nodes like Integrations. These nodes can have unpredictable execution times and can cause timeouts or errors if chained. It is better to use asynchronous integrations or message events to decouple the process flow

from external systems.

Move transactions that can be done asynchronously outside of the chain. This can improve the responsiveness of the process model and allow parallel processing of independent tasks.

Therefore, the correct answers are B, C, and D.

References:

Activity Chaining

Performance Best Practices

Correct Answer: D

A materialized view is the best option to show joined data from 5 tables that contain a large number of rows and could generate a large result set after executing the joins. A materialized view is a physical table that holds the results of the SQL that a view would normally be constructed from and can be generated periodically. A materialized view can improve performance by reducing the execution time of complex queries that involve multiple joins, aggregations, or calculations. A materialized view can also reduce the load on the database server by storing the query results in advance. A materialized view can be refreshed at regular intervals or on demand to reflect the changes in the underlying tables. References: [Materialized Views], [View Performance]

Correct Answer: D

The most efficient method to insert the deleted row of a table into a history table for audit purposes is Trigger. This is because a trigger is a database object that automatically executes a specified SQL statement when a certain event occurs on a table or view. A trigger can be defined to run before or after a delete operation on a table, and can access the deleted row using a special table called deleted. A trigger can perform the insertion of the deleted row into the history table without any additional logic or overhead from Appian. References: Triggers

Correct Answer: B

The appian_log4j.properties file is used to configure the logging levels for Appian components, including authentication. You can modify this file to increase or decrease the verbosity of the log output for different categories. For example, to enable trace-level logging for SAML authentication, you can add this line to the file: log4j.logger.com.appiancorp.suite.authentication.saml=TRACE References: [Appian Logging Configuration], [SAML Troubleshooting]

Correct Answer: C

The correct representation of Appian best practices for using pie charts is to use pie charts to show proportional data. Pie charts are generally used to show how individual parts contribute to a whole, such as percentages or fractions. Pie charts should only be used to represent data that can be placed into distinct categories and should not consist of more than 6 slices. Pie charts should also include value and category labels for each slice, and sort the data values in ascending or descending order. References: Pie Chart Component, Charts UX Design Guide

Correct Answer: AC

Two true statements are: It is not possible to undo changes from an import to all types of objects. Once a package is imported to an environment, it applies changes to the existing objects or creates new objects based on the package contents. There is no built-in mechanism to revert these changes or delete these objects automatically. Therefore, it is important to test the package in a non-production environment before importing it to production, and to backup any objects that may be overwritten by the import. It is possible to import the same package multiple times. A package can be imported to an environment more than once, as long as it does not contain any conflicts or errors that would prevent the import. However, importing the same package multiple times may not have any effect if there are no changes in the package contents or in the target environment since the last import. References: Prepare Deployment Packages, Application Deployment Guidelines

Correct Answer: A

The most likely root cause of the error is that the view contains a large number of rows, requiring more time to fetch the data. This can result in a timeout or an out-of-memory error. To avoid this, you can use pagination or filters to limit the number of rows returned by the view. You can also optimize the view performance by using indexes, avoiding unnecessary joins, and reducing the number of columns. References: [Views], [View Performance]

Correct Answer: B

The question is about a sign that an application's performance is degrading and should be addressed with changes to the application design. The following is a sign of this: Three of the top five most executed process models have a low completion percentage. This means that a large proportion of the process instances are not reaching the end event, either because they are taking too long to complete, or because they are encountering errors or exceptions. This can affect the performance of the application, as it can consume more memory and resources, and reduce the availability and reliability of the application. You should review the process model design and identify the causes of the low completion rate, and make changes to improve the process efficiency and error handling. The following are not signs of performance degradation that require changes to the application design: Integration calls to an external system are consistently returning an HTTP status code of 500. This means that the external system is experiencing an internal server error, which is not related to the application design. You should contact the external system provider and report the issue, or implement a fallback or retry mechanism in your integration logic. The number of tasks assigned to users has increased from 1 per day to 5 per day. This means that the workload or demand for the application has increased, which is not necessarily a sign of performance degradation. You should monitor the task completion rate and user feedback to see if the increase in tasks is affecting the user experience or satisfaction, and adjust the task assignment or prioritization logic if needed. The number of objects in the Application has increased from about 100 to about 500. This means that the application has grown in size and complexity, which is not necessarily a sign of performance degradation. You should follow the best practices for application design and maintenance, such as using folders, prefixes, dependencies, and documentation, to keep the application organized and manageable. References: Process Model Metrics HTTP Status Codes Task Report Application Design

Correct Answer:
