72201X Online Practice Questions and Answers

A remote worker using the Avaya Communicator on a mobile phone obtains a private IP address delivered from the corporate network over WiFi when in range of the wireless hot- spot. When the remote worker is out of range of the corporate WiFi, it obtains a Public IP address via the 3G/4G mobile Service Provider. What strategy prevents the user from having to change the SIP Proxy Server address in the smartphone when roaming between the public and corporate private networks?

A. Network Address Translation (NAT)

B. Avaya Session Border Controller for Enterprise (SBCE) public IP-address

C. Split Horizon DNS with FQDN

D. Virtual Private Network (VPN)

How can an inactive SM100 be reset?

A. Click the repair button on the Replication page with the affected Avaya Aura Session Manager (SM) selected.

B. Click the 'Reset' button on the Security Module Status page in Avaya Aura System Manager (SMGR).

C. Run the resetSM100 command from RHEL Command Line Interface of Avaya Aura Session Manager (SM)

D. Restart Services on the Avaya Session Border Controller for Enterprise (SBCE).

E. Run the reboot SM100 command from RHEL Command Line Interface of Avaya Aura System Manager (SMGR).

F. Use the SMGR web interface to reset the SM100 by navigating to Services > Security > Security Module.

A customer states they are having voice quality issues when they make calls over a WAN link. You would like to see what the Quality of Service is for a call, as the customer makes the call. Which Avaya Aura Communication Manager (CM) SAT command will display packet loss and jitter for a call in progress?

A. monitor station qos xxxx, where XXXX is the station number

B. list monitor qos

C. status station qos xxxx, where XXXX is the station number

D. list trace station xxxx, where XXXX is the station number.

E. status media-gateway

F. list trace h248

Which two methods are used to obtain Avaya Aura Communication Manager (CM) software version information? (Choose two.)

A. In CM SMI, navigate to Administration > Server Maintenance > Server > Software Version.

B. In Avaya Aura System Manager (SMGR), navigate to Services>; Inventory>; Managed Elements.

C. In Linux, issue the swversion. command.

D. In Linux, issue the software version show.command.

E. In CM SAT, issue the display software version. command.

F. In CM SAT, issue the list software version. command.

How can you show that a session is actually reaching the Avaya Aura Media Server (AAMS)?

A. In AAMS Element Manager, Select System Status > Element Status > More Actions > display active sessions.

B. From SSH, go to the AAMS and issue the list active sessions current. command.

C. In AAMS Element Manager select Monitoring > Active Sessions.

D. From Avaya Aura System Manager (SMGR) home page, click on the Media Server, and click on the link: list active sessions.

E. Use the command 'show sessions' on the Media Server CLI.

After a successful registration, how does an Avaya SIP telephone learn if any of its Call Forward features are active at the moment?

A. It queries the LDAP database for active feature status.

B. It sends a Subscribe ?avaya-cm-feature-status event package to Aura Communication Manager (CM) via Aura Session Manager (SM).

C. It sends a PPM getDeviceData request to Aura Session Manager (SM); Aura Session Manager (SM) replies with a getDeviceData response.

D. It sends a Subscribe ?avaya-ccs-profile event package to Aura Session Manager (SM); Aura Session Manager (SM) in turn replies with a Notify-avaya-ccs-profile.

E. It sends a SIP INFO request to Aura Session Manager (SM), which replies with the active Call Forwarding status.

Which four traces options can be useful when troubleshooting SIP endpoint registration issues with a phone using TCP protocol? (Choose four.)

A. SIP Registration

B. TLS handshaking

C. PPM

D. Call Processing

E. Network Interface

F. SIP Signaling

G. RTP Flow

Refer to the Exhibit.

What happens when a call is made from AST 1011111 to AST 1011112? (Choose three.)

A. In step 3, Avaya Aura Communication Manager (CM) sends SIP Options to 1011112 looking for a 200 ok response to check it is reachable.

B. In step 2, Avaya Aura Session Manager (SM) matches 1011111 with a Communication Profile, and uses the defined Originating Application Sequence to route the call to Avaya Aura ?Communication Manager.

C. In step 1, when 1011111 draws dial tone it sends an Invite to Avaya Aura Session Manager (SM) with the Request URI containing 1011111.

D. In step 2, the Avaya Aura Session Manager (SM) uses a dial pattern and routing policy to route the call to Avaya Aura Communication Manager (CM).

E. In step 4, Avaya Aura Communication Manager (CM) sets up the media path between the two endpoints.

F. In step 5, the call is terminated by either endpoint or by a network failure.
