220-1101 Online Practice Questions and Answers

Correct Answer: A

The technology that allows multiple networks to traverse a switch is VLAN (Virtual Local Area Network) which is a logical grouping of devices on the same network regardless of their physical location12.

Virtual Local Area Network (VLAN) technology can allow multiple networks to traverse a switch. A VLAN is a logical network created within a physical network that can separate traffic and allow multiple networks to coexist on the same

physical network infrastructure. VRRP (Virtual Router Redundancy Protocol), VPN (Virtual Private Network), and DHCP (Dynamic Host Configuration Protocol) do not allow multiple networks to traverse a switch. References: CompTIA A+

Certification Exam: Core 1 - Objective 3.2

Correct Answer: C

In this situation, the best course of action for the technician to take NEXT would be C. Verify the socket type and manufacturer. If the pins on the CPU do not line up with the socket on the motherboard, it is likely that there is a compatibility issue between the two components. The technician should verify that the socket type and manufacturer of the motherboard match those of the CPU to ensure that they are compatible.

Correct Answer: D

Correct Answer: B

Vertical or horizontal lines--Marks that appear in the same place (referred to as repetitive defects) are often due to dirty feed rollers (note that there are rollers in the toner cartridge and fuser unit too) or a damaged or dirty photosensitive drum. Vertical streaks on a laser printer output are usually caused by a damaged or worn-out drum, which is responsible for transferring toner to the paper. If the drum is damaged, toner may accumulate on certain parts of the drum, leading to streaks on the printed output. References: CompTIA A+ Certification All-in-One uide, Tenth Edition, Chapter 15

Correct Answer: A

Near field communication (NFC) is a function that enables contactless payments with a phone by allowing it to communicate with compatible devices within close proximity. If NFC is not working properly, the user will not be able to perform contactless payments with the phone. Hotspot is a feature that allows a device to share its internet connection with other devices via Wi-Fi, Bluetooth, or USB. Bluetooth is a wireless technology that allows devices to connect and exchange data over short distances. USB is a standard interface that connects devices such as keyboards, mice, flash drives, etc

Correct Answer: C

The message prompting to press "OK" indicates that the printer is waiting for a user input. This suggests that there is some issue with the printer settings, and the most probable cause is that the default paper type has been changed, and the printer needs the user to confirm the paper type before proceeding with the print job. This is a common issue that can occur when the default paper type is not set correctly or has been changed without the user's knowledge.

Correct Answer: CD

A cable tester and a crimper are the best tools to execute the task of replacing all RJ45 cables in a customer environment. A cable tester can be used to check the continuity and quality of a cable, and a crimper can be used to attach RJ45 connectors to the ends of a cable. An optical fiber tester is a tool that can be used to test fiber optic cables, which are not RJ45 cables. Scissors are not a tool for replacing cables, but for cutting them. A coaxial cable is a type of cable that has a single copper conductor at its center, which is not an RJ45 cable either. A screwdriver is not a tool for replacing cables, but for fastening or loosening screws.

Correct Answer: D

Liquid cooling is a method of cooling the CPU by circulating a liquid through a closed loop that absorbs heat from the CPU and transfers it to a radiator. Liquid cooling is more effective and quieter than air cooling, which uses a fan and a heat sink. However, liquid cooling is also more expensive and complex to install. Upgrading the thermal paste, using a copper heat sink, or upgrading the CPU fan are ways to improve air cooling, but they will not lower the CPU temperature as much as liquid cooling. References: https://www.comptia.org/certifications/a#examdetails https://www.comptia.org/blog/what-is- liquid-cooling

Correct Answer: B

Explanation: An F-type connector is a coaxial RF connector that is commonly used for cable television, satellite television, and cable modems. An internet service provider (ISP) may use an F-type connector to connect the coaxial cable from the wall outlet to the cable modem or the set-top box. The F-type connector has a threaded interface that provides a secure and reliable connection. The F-type connector can also support high-frequency signals up to several GHz, which can deliver high-speed internet and high-definition television. Other scenarios, such as making a serial connection to a hardware device, purchasing a charging cable for a laptop, or upgrading the service on an electrical panel, are not likely to use an F-type connector. A serial connection to a hardware device may use a DB-9 or a DB-25 connector, which are D-shaped connectors with pins. A charging cable for a laptop may use a USB or a barrel connector, which are flat or cylindrical connectors with contacts. An electrical panel may use a twist-lock or a pin-and-sleeve connector, which are round connectors with locking mechanisms. References: F connector - Wikipedia1 F-Type Connectors - RF Connectors | Amphenol RF2 How to Install F Connectors on Coaxial Cable - The Spruce3

Correct Answer: B

The first thing that the technician should check when troubleshooting a wireless network issue with slow throughput and frequent connection drops is the channel interference. Channel interference is a common cause of poor Wi-Fi performance, as it occurs when multiple wireless networks or devices use the same or overlapping frequency bands, resulting in signal degradation, congestion, or collision. Channel interference can affect both 2.4 GHz and 5 GHz networks, but it is more likely to happen on the 2.4 GHz band, as it has fewer and narrower channels than the 5 GHz band. To check for channel interference, the technician can use a Wi-Fi analyzer tool, such as the ones found in the web search results123, to scan the wireless environment and identify the best channel to use for the network. A Wi-Fi analyzer tool can display various information, such as the network name (SSID), signal strength (RSSI), channel number, frequency, bandwidth, and security type. The technician can look for the following indicators of channel interference: High network density: If there are many wireless networks or devices in the vicinity, they may compete for the same or adjacent channels, causing interference and congestion. The technician can look for the number of networks or devices on each channel and avoid the crowded ones. Channel overlap: If there are wireless networks or devices that use the same or partially overlapping channels, they may interfere with each other and degrade the signal quality. The technician can look for the channel width and frequency of each network and avoid the overlapping ones. For example, on the 2.4 GHz band, the technician should use only the non-overlapping channels 1, 6, and 11, and avoid the channels in between. Signal interference: If there are other sources of electromagnetic radiation or noise that operate on the same or similar frequency bands as the wireless network, they may interfere with the wireless signals and cause distortion or loss. The technician can look for the signal strength and quality of each network and avoid the ones that are weak or noisy. For example, some common sources of signal interference are microwave ovens, cordless phones, Bluetooth devices, or baby monitors. To fix the channel interference issue, the technician can try the following solutions: Change the channel of the wireless network: The technician can use the Wi-Fi analyzer tool to find the least congested and most optimal channel for the network, and then change the channel settings on the router or the access point. The technician should also consider using the 5 GHz band instead of the 2.4 GHz band, as it offers more and wider channels and less interference. Relocate the router or the access point: The technician can move the router or the access point to a different location, away from potential sources of interference or obstacles that may block or weaken the wireless signals, such as walls, furniture, or metal objects. The technician should also place the router or the access point in a central and elevated position, to provide better coverage and signal quality for the network. Upgrade the router or the access point: The technician can replace the router or the access point with a newer and more advanced model, that supports the latest Wi-Fi standards, such as Wi-Fi 6 (802.11ax) or Wi-Fi 5 (802.11ac). These standards offer higher data rates, lower latency, and better performance in dense and noisy environments, compared to the older standards, such as Wi-Fi 4 (802.11n) or Wi-Fi 3 (802.11g). References: How to Fix Wi-Fi Connection Drops - Lifewire4 How to Fix When Wi-Fi Keeps Disconnecting on Windows 115 How to Fix Wi-Fi Connection Drops - Lifewire6 How to Fix Wi-Fi Connection Drops - Lifewire7 How to Fix Wi-Fi Connection Drops - Lifewire8

Correct Answer: C

Explanation: A digitizer is a component that converts the touch input on a tablet screen into digital signals that can be processed by the device. A digitizer consists of a thin layer of transparent material that covers the glass screen and has sensors that detect the position and pressure of the touch. If the digitizer is damaged, misaligned, or poorly calibrated, it can cause inaccurate touch input, such as selecting the wrong item or not responding at all12. Therefore, the most likely cause of the issue in this scenario is a faulty digitizer that may need to be replaced. The other components are not directly related to the touch input functionality of the tablet. A gyroscope is a sensor that measures the orientation and rotation of the device3. A battery is a power source that supplies electricity to the device4. A glass is a protective layer that covers the screen and prevents scratches and cracks5. References

1: What is a Digitizer? - Definition from Techopedia

2: How to Fix a Broken Digitizer on a Tablet | Chron.com

3: What is a Gyroscope Sensor in Mobile Phones? - Definition from Techopedia

4: What is a Battery? - Definition from Techopedia

5: What is Glass? - Definition from Techopedia

Correct Answer: D

Correct Answer: C

Correct Answer: B

Correct Answer:
